Automatic Vertical Form Fill Seal Packaging Machine
|
Technical Parameters |
|||
|
Model |
FY-430 |
FY-630 |
FY-830 |
|
Bag size |
(L） 80-300mm (W) 80-200mm |
(L) 100-400mm (W) 100-300mm |
(L) 100-500mm (W）100-400mm |
|
Film width |
Max.430mm |
Max.630mm |
Max.830mm |
|
Film thickness |
0.04-0.12mm（confirm when order） |
||
|
Packing speed |
20-110bags/min |
20-50bags/min |
15-30bag/min |
|
Air consumption |
0.65Mpa, 0.4m³/min |
||
|
Packing material |
All laminated film such as PET/PE, PET/AL/PE, Nylon/PE, etc.; PE (confirm when order) |
||
|
Power supply |
220V/380V 50-60Hz |
||
|
Power |
2.8Kw |
3.0Kw |
3.5Kw |
|
Dimension |
L1660x W1060 x H1500mm |
L1740x W1350 x H1950mm |
L2090x W1545 x H2300mm |
|
Weight |
350Kg |
450Kg |
550Kg |
Product Introduction
- Low investment, high return, high speed and high efficiency.
- PLC full computer control system with human-machine interface and large touch screen for easy operation.
- Servo film feeding system, with servo/pneumatic control for transverse sealing, ensuring accurate positioning and excellent overall performance, which maximizes the reliability and intelligence of the machine.
- Equipped with a metering device, this machine can automatically complete the whole process of feeding, bag making, filling, date printing, inflation (deflation), counting and finished product output.
- Bag styles: The machine can produce pillow bags, vertical bags, punched bags, multi-connected packs and half-punched multi-connected packs according to customer requirements.
Need a Suitable Vertical Packaging Machine?
We provide custom automatic packaging solutions for powder, granule, liquid and paste.
